TCW Safety-Trim Dual axis servo controller

Part No: ST-2-12V

$285 COP
Impuestos incluidos El envío será calculado durante el checkout.
Option: Standard
DESCRIPCIÓN

Safety-Trim is an electronic speed controller designed specifically to operate the electric servo trim tabs found on many experimental category aircraft.  Safety-Trim does more than just provide the switching and speed control functions typically used to operate standard servos. It provides an important safety feature that greatly reduces the possibility of run-away trim conditions. The technology implemented in Safety-Trim ensures that the trim servo(s) being operated are not accidentally driven to the limits by common problems, such as stuck, welded or inoperative input switches, inadvertent contact of input switches, and failed electrical components. Additionally, Safety-Trim provides a way to recover from an inoperative trim switch, allowing the pilot to get the plane trimmed back to neutral.

Stand alone trim models are available in single or dual axis controllers, 2 speed presets for high and low speed trim actuation that allow separately adjustable trim speeds for different flight configurations.  Both the regular single-axis and dual-axis models also have a reverse function.  Safety-Trim works for applications involving DC trim motors rated for operation at 12 volts DC and up to 1 amp.  Safety-Trim is designed specifically to operate electronic servo motors, such as the Ray-Allen T2 and T3 series and also has an output which may be used to power the Ray-Allen trim position indicator (14 volt operation only, up to 100m Amps max).

Safety-Trim is also available in a single axis heavy-duty model for DC trim motors and linear actuators rated for operation at 12 volts and up to 10 amp.

Safety Trim is also available in two servo booster models for autopilot systems in either 12 or 24 volts.  Safety Trim Servo Booster is designed specifically to receive input commands from compatible autopilot systems, such as the Garmin G3x GSA 28 or a traditional dpdt type rocker switch.  Safety Trim Servo Booster operates DC electric servo motors up to 10 amps of rate current.



Safety-Trim Intelligent Servo Controller Specifications

Non-Certified



All Safety-Trim Single and Dual Axis Servo Controllers

Input Voltage *:

10 – 30 volts DC

Output Voltage:

User adjustable 6-12 volts DC, 1 amp maximum

Inputs:

Trim switch inputs, closures to ground

pilot/co-pilot switches wired in parallel

2 speed switch, closure to ground

Output:

Time limited, controlled DC voltage to servo
Time limit factory set to 3 seconds

Wiring:

Standard 15-pin D-sub connector (male on controller) pre-made wiring harness with ON/OFF/Reverse switch available

Enclosure:

Overall dimensions 5.7” x 2.5” x 1.5”

UL 94V-0 rated material, 60°C max temperature

Weight:

6 oz.

*2 speed models: factory calibrated for most RV aircraft; user adjustable. Units are furnished complete with detailed instructions. Standard 15 pin D-sub female connector required on the aircraft wiring harness (not included with the Safety Trim Controller).

For Experimental Aircraft Only, not TSO’d
